DURAMAX Index.
If you are in the market for a Duramax-equipped Light-Duty Pick-up you should read this.
All models utilize Aluminum heads and weigh roughly 835 pounds dry. Allison 1000 transmissions weigh roughly 330 pounds.
LB7: ’01-‘04
LLY: ‘04.5-‘06
LBZ: ’06-‘07
LMM: ’07.5-09
LML: ’11+

Duramax Engines in Chronological order:


Years offered: 2001-2004
Engine Code: LB7
8th Digit VIN Identifier: 1
Specifications:
Engine type: 6,599 cc (6.599 L; 402.7 cu in) V8 turbo
Bore x Stroke: 4.06 in (103.1 mm) x 3.90 in (99.1 mm)
Block / Head: Cast gray iron / Cast aluminum
Aspiration: Turbocharged & Intercooled
Valvetrain: OHV 4-V
Compression: 17.5:1
Injection: Direct; Bosch High Pressure Common-rail
Power / Torque: 300 HP @ 3100rpm / 520 LB-FT @1800 rpm


Engine Changes from previous model: First Year of production. First Common-Rail injected diesel in light-duty vehicles. The LB7 is known for fuel mileage as it had the least emissions control equipment and programming.


Transmission Model & Gears: Automatic: Allison 1000 5-Speed; 1st-3.10 2nd-1.81 3rd-1.41 4th-1.00 5th-0.71 Rev.-4.49. Manual: ZF-6 ZF S6-650 6-Speed; 1st-5.79 2nd-3.31 3rd-2.10 4th-1.31 5th-1.00 6th-0.72 Rev.-5.23

Transmission Changes from previous model: Introduction of Allison LCT-1000. First Allison transmission in light-duty vehicles.


Transfer Case: NP263XHD Electric Shift; NP261XHD Manual


Transfer Case Changes from previous model: First year of production

Known Motor/Transmission/Transfer Case issues:
Recall for faulty glow plugs from the factory; warranty is 10yrs/200K miles.
Recall Gauge cluster for faulty backlighting; warranty is 7yrs/75Kmiles.
Injector Failure. Valve covers must be removed to R&R injectors.
Injector Harness issues caused by wires rubbing against mount
Transfer Case pump rub issue due to faulty/poorly designed wear indicator retaining clip. The clip rubs a hole in the magnesium case, 246/261/263-series.

Changes to Vehicle from previous model: First GMT800 platform. Model Year 2003 marked with body changes; significant changes to front clip.

Known Major Vehicle Issues:
Tie-rod failure due to 4WD boosted launches or off-roading

Popular Mods:
Aftermarket intake
Programmer/Tuner/Custom Tuning
Turbo-Back exhaust
Resonator removal and block.
Lift Pump
Transmission Upgrades
HD Tie-rods/Sleeves


Years offered: 2004.5-2005/ 2006 LLY is basically a de-tuned LBZ
Engine Code: LLY
8th Digit VIN Identifier: 2
Specifications:
Engine type: 6,599 cc (6.599 L; 402.7 cu in) V8 turbo
Bore x Stroke: 4.06 in (103.1 mm) x 3.90 in (99.1 mm)
Block / Head: Cast gray iron / Cast aluminum
Aspiration: Turbocharged & Intercooled
Valvetrain: OHV 4-V
Compression: 17.5:1 / 16.8:1 (2006)
Injection: Bosch High Pressure Common-rail
Power / Torque: 04.5-06; 310 HP @3000rpm / 605 LB-FT @1600 rpm.

Engine Changes from previous model:
Garrett Variable Geometry Turbocharger (VGT)
EGR Valve added
PCV now routed back through Turbo Air Intake (mouthpiece)
Redesigned Valve Covers, eliminating removal to R&R injectors and prevent fuel from pouring into crank-case
Grid Heater removed
High Idle Feature added
Early 2006 LLY model has LBZ updates including Bosch ECM and internals.

Transmission Model & Gears: Automatic: 2004.5-05; Allison 1000 5-Speed 1st-3.10 2nd-1.81 3rd-1.41 4th-1.00 5th-0.71 Rev.-4.49. 2006; Allison 1000 6-Speed 1st-3.10 2nd-1.81 3rd-1.41 4th-1.00 5th-0.71 6th-0.61 Rev.-4.49. Manual: ZF-6 ZF S6-650 6-Speed; 1st-5.79 2nd-3.31 3rd-2.10 4th-1.31 5th-1.00 6th-0.72 Rev.-5.23

Transmission Changes from previous model: None

Transfer Case: NP263XHD Electric Shift; NP261 XHD Manual



Transfer Case Changes from previous model: None

Known Motor/Transmission/Transfer Case issues:
Over-heating issues commonly reported
http://www.thedieselgarage.com/forums/forumdisplay.php?f=217
Restrictive mouthpiece
Injector Harness issues caused by wires rubbing against mount
Transmission overheating in cold temperatures, resolved with a TCM reflash (2006 Allison)
Transmission lines leaking at crimped couplers
Transfer Case pump rub issue due to faulty/poorly designed wear indicator retaining clip. The clip rubs a hole in the magnesium case, 246/261/263-series.

Changes to Vehicle from previous model: Higher Hood-line signifying Model Year 2005+

Known Major Vehicle Issues:
Tie-rod failure due to 4WD boosted launches or off-roading

Popular Mods:
Aftermarket intake
Programmer/Tuner/Custom Tuning
Cat-Back exhaust
Turbo-Back exhaust
LBZ/LMM/Kodiak or aftermarket mouthpiece upgrade
Resonator removal and block
PCV Re-Route
EGR Blocker Plate & Finger Stick
Race Fuel Valve
Lift Pump
Transmission Upgrades
HD Tie-rods/Sleeves


Years offered: 2006-2007
Engine Code: LBZ
8th Digit VIN Identifier: D
Specifications:
Engine type: 6,599 cc (6.599 L; 402.7 cu in) V8 turbo
Bore x Stroke: 4.06 in (103.1 mm) x 3.90 in (99.1 mm)
Block / Head: Cast gray iron / Cast aluminum
Aspiration: Turbocharged & Intercooled
Valvetrain: OHV 4-V
Compression: 16.8:1
Injection: Bosch High Pressure Common-rail
Power / Torque: 360 HP @3200rpm / 650 LB-FT @1600 rpm


Engine Changes from previous model:
Cylinder block casting and machining changes strengthen the bottom of the cylinder bores to support increased power and torque
Upgraded main bearing material increases durability
Revised piston design helps lower compression ratio to 16.8:1 from 17.5:1
Piston pin bore diameter increased for increased strength
Connecting rod “ I ” section is thicker for increased strength
Cylinder heads revised to accommodate lower compression and reduced cylinder firing pressure
Maximum injection pressure increased from 23,000 psi (1,585.8 bar) to more than 26,000 psi (1,792.6 bar)
Fuel delivered via higher-pressure pump, fuel rails, distribution lines and all-new, seven-hole fuel injectors
Fuel injectors spray directly onto glow plugs, providing faster, better-quality starts and more complete cold-start combustion for reduced emissions
Improved glow plugs heat up faster through an independent controller
Revised variable-geometry turbocharger is aerodynamically more efficient to help deliver smooth and immediate response and lower emissions
Air induction system re-tuned to enhance quietness
EGR has larger cooler to bring more exhaust into the system
First application of new, 32-bit E35 controller, which adjusts and compensates for the fuel flow to bolster efficiency and reduce emissions"
Grid Heater Standard again

Transmission Model & Gears: Allison 1000 6-Speed 1st-3.10 2nd-1.81 3rd-1.41 4th-1.00 5th-0.71 6th-0.61 Rev.-4.49.

Transmission Changes from previous model: Change to 6-Speed and upgraded C2 Apply took place in Model Year 06. Different TCM and NSBU, no longer uses Torque Converter speed in management strategy, instead uses ECM RPM. Shifter is now triangular and has a + and – button to manipulate shifting while in manual mode.


Transfer Case: NP263XHD Electric Shift; NP261 XHD Manual

Transfer Case Changes from previous model: Pump-Rub issue resolved in Model Year 07 when the case went back to Aluminum.

Known Motor/Transmission/Transfer Case issues:
Pistons are prone to failure when subjected to extreme fueling and injection timing due to aggressive programming and not maintaining a high enough rail fuel pressure.
Transmission overheating in cold temperatures, resolved with a TCM reflash
Transmission lines leaking at crimped couplers

Changes to Vehicle from previous model:
Minor updates to interior dash/waterfall
Known Major Vehicle Issues:
Tie-rod failure due to 4WD boosted launches or off-roading

Popular Mods:
Airbox mod or aftermarket intake
Programmer/Tuner/Custom Tuning
Cat-Back exhaust
Turbo downpipe-back exhaust
Resonator removal and block.
PCV Re-Route
EGR Blocker Plate & Finger Stick
Race Fuel Valve
Lift Pump
Transmission Upgrades
HD Tie-rods/Sleeves

Years offered: 2007.5-09

Engine Code: LMM


8th Digit VIN Identifier: 6


Specifications:

Engine type: 6,599 cc (6.599 L; 402.7 cu in) V8 turbo
Bore x Stroke: 4.06 in (103.1 mm) x 3.90 in (99.1 mm)
Block / Head: Cast gray iron / Cast aluminum
Aspiration: Turbocharged & Intercooled
Valvetrain: OHV 4-V
Compression: 16.8:1
Injection: Bosch High Pressure Common Rail with CP3.3 Injection Pump
Horse Power / Torque: 365 HP @3200rpm / 660 LB-FT @1600 rpm

Engine Changes from previous model:
Additional combustion control, including an even more efficient variable-geometry turbocharging system, cooled (enhanced) exhaust gas recirculation (EGR) and closed crankcase ventilation to reduce nitrogen oxides (NOx)
Additional exhaust control, including oxidizing catalyst and new diesel particulate filter (DPF) to reduce soot and particulate matter
Increased-capacity cooling system
New engine control software
Use of low-ash engine oil (CJ-4)

Transmission Model & Gears: Allison 1000 6-Speed 1st-3.10 2nd-1.81 3rd-1.41 4th-1.00 5th-0.71 6th-0.61 Rev.-4.49

Transmission Changes from previous model: Change to 6-Speed and upgraded C2 Apply took place in Model Year 06.

Transfer Case: NP263XHD Electric Shift; NP261 XHD Manual

Transfer Case Changes from previous model: Pump-Rub issue resolved in Model Year 07

Known Motor/Transmission/Transfer Case issues:
LMM DPF and tuning do not mix well. Regeneration issues may occur and many have been reported. Generally DPF-deleted and tuned LMM trucks experience 1-2MPG better fuel economy than DPF-equipped LMM trucks.


Changes to Vehicle from previous model:
Introduction of GMT-900, new body and interior. Silverado and Sierra have more distinct body differentiation. Two dash layouts; Luxury dash that closely mimics the dash in their GMT900 SUVs, and a Pure Truck dash that is more upright to make way for a passenger seat in place of a center console. Integrated Trailer Brake Controller (ITBC) is now optional.

Known Major Vehicle Issues: Numerous rattles and nit-picks. Frequent accidental 4WD engagement due to location of new 4WD knob and lack of 4WD indicator LED in Dash.
Snow in the air box leading to CEL. There is a TSB to mod the box and grill opening.
http://www.thedieselgarage.com/forums/showthread.php?t=83253
Tie-rod failure due to 4WD boosted launches or off-roading

Popular Mods:
Air Box Mod or aftermarket intake system.
Programmer/Tuner/Custom Tuning
DPF-back exhaust (aesthetics only)
DPF/CAT delete with tuning and Turbo downpipe-back exhaust
PCV Re-Route
Resonator removal and block.
EGR Blocker Plate

Race Fuel Valve
Lift Pump
Transmission Upgrades
HD Tie-rods/Sleeves



Years offered: 2011+

Engine Code: LML


8th Digit VIN Identifier: ?


Specifications:

Engine type: 6,599 cc (6.599 L; 402.7 cu in) V8 turbo
Bore x Stroke: 4.06 in (103.1 mm) x 3.90 in (99.1 mm)
Block / Head: Cast gray iron / Cast aluminum
Aspiration: Turbocharged & Intercooled
Valvetrain: OHV 4-V
Compression: 16.8:1
Injection: Bosch High Pressure Common Rail with CP4.2 Injection Pump
Horse Power / Torque: 375 HP(EST.) @3200rpm / 700 LB-FT(EST.) @1600 rpm



Engine Changes from previous model:
Injectors are now piezo controlled
Urea injection aftertreatment (DEF) to meet ’11 EPA standards
Dual Loop EGR system
DPF system now has a 9th injector behind turbo
B5 and B20 compatible with new fuel lines, fuel system heater element and latest coalescing filter



General Info on ancillary parts:
Allison 1000
http://www.allisontransmission.com/servlet/DownloadFile?Dir=publications/pubs&FileToGet=SA5521EN.pdf
AAM 9.25 IFS front axle(4WD) and AAM 11.50 rear axle, with optional G80 RPO Code Eaton locker availability retained.
http://www.eaton.com/EatonCom/Markets/Automotive/ProductsandSolutions/Differentials/index.htm
<font face="&quot">http://www.youtube.com/watch?v=KbMZ9vcYVSg</font>
<font face="&quot">http://www.youtube.com/watch?v=KbMZ9vcYVSg</font>


DURAMAX Performance & Tuning
Programmers/Tuners
Intake
Intercooler
Exhaust
Turbo
Fuel
Transmission
Steering
Engine
Swap/Conversion

Programmers/Tuners

There are different types of Programmers/Tuners

Portable/Hand-Held tuners that program the ECM through the OBDII port.
i.e. EFILive & PPE Xcelerator

Vehicle-Mounted tuners that program the ECM through the OBDII port. Most feature a remote display to adjust power levels and gauges.
i.e. Edge Evolution, Evolution CS & CTS

Vehicle-Mounted In-Line tuners that control certain parameters and install between the ECM and engine/FICM?MAF/MAP harness. Most feature a remote display to adjust power levels and gauges. Many believe these do not leave a foot print or are not detectable.
i.e. Edge Juice w/Attitude, Banks & TS MP8.

Programmers & Tuners:

Portable/Hand-Held;
PPE Xcelerator (Four models but each works with all Duramax models)
http://www.pacificp.com/chevy-xcell.php
6-10 levels, Speedo correction, Speed limiter removal, +2-3 mpg, DTC code reading/clearing, Gear Ratio Adjustment and Defueled Shift Option. Hot and Hot+2E.T. can be used to DPF delete an LMM Duramax


+425 HP / +620 LB-FT MAX

EFILive w/ FlashScan V2 Scan & Tune w/2 VIN Licenses (Custom Tuning available from numerous sources)
http://www.efilive.com/index.php?page=shop.product_details&flypage=flypag e_EFILive.tpl&product_id=63&category_id=11&option= com_virtuemart&Itemid=56
Infinite Tuning and Diagnostic Capability, Data Logging and more….

Bully Dog Triple Dog/Triple Dog E3 and Power Pup
http://www.bullydog.com/categories/index/category_page/56
+120 HP MAX

DiabloSport Predator LLY/LBZ/LMM
http://www.diablosport.com/index.php?module=htmlpages&func=display&pid=3
+120 HP MAX

H&S XRT LMM
http://www.hsperformance.com/store/index.php?p=product&id=53&parent=13
+180 HP MAX

HyperTech Max Energy Power/Economy
http://go.hypertech.com/hypertech/products-max-energy-diesel.aspx
http://go.hypertech.com/hypertech/products-max-energy-econ-diesel.aspx
+113 HP / +185 LB-FT MAX

Quadzilla Stealth2 LMM Model can program for DPF Delete
http://www.quadzillapower.com/products/index.cfm/p/Stealth2
+215 HP / +415 LB-FT MAX
Superchips Flashpaq, Mileage Max and Cortex
https://www.superchips.com/#pn=home
+119 HP / +206 LB-FT MAX

Vehicle-Mounted OBDII;

Edge Evolution or Evolution Race 2.4” LCD
Edge Evolution CS (CS Race) 2.5” Color Screen or Evolution CTS (CTS Race) 4.3” Color Touch Screen
http://www.edgeproducts.com/products.php?car_motor_key=75&category_key=all
7 Levels, DTC code reading/clearing Displays up to 8 parameters at a time in digital display mode, Monitors and displays DPF status (LMM), (Race versions can program for DPF delete on LMM)
+180 HP / +395 LB-FT MAX (Modest)

Bully Dog Power Management Tool or Triple Dog GT
http://www.bullydog.com/categories/index/category_page/56
+140 HP / +200 LB-FT MAX

DiabloSport Trinity
http://www.diablosport.com/index.php?module=htmlpages&func=display&pid=151
+120 HP MAX

H&S Black Maxx/Active Maxx LMM
http://www.hsperformance.com/?page_id=1315
+175 HP MAX

HyperTech HyperPAC
http://go.hypertech.com/hypertech/products-hyperpac.aspx
+113 HP / +185 LB-FT MAX

Vehicle-Mounted In-Line;
Edge Juice w/Attitude 2.4” LCD
http://www.edgeproducts.com/view_all_products.php
5-6 Adjustable on-the-fly levels, DTC code reading/clearing Displays up to 4 parameters at a time in digital display, Monitors and displays DPF status (LMM)
+150 HP / +350 LB-FT MAX

Banks EconoMind or 6-Gun/6-Gun w/Speed Loader available with Power PDA (Palm Tungsten-Discontinued) or IQ Display unit (5+” Touch Screen)
http://www.bankspower.com/app/index/1#
6 Adjustable on-the-fly levels, DTC code reading/clearing Displays up to 4 parameters at a time in digital display (PDA)
+100 HP / +233 LB-FT EconoMind MAX
+155 HP / +385 LB-FT 6-Gun w/SL or PDA Max

TS Performance MP8
http://www.tsperformance.com/Power_Play.html
3 Levels, Fueling box (Very popular for stacking)
+100 HP MAX

Quadzilla Adrenaline with Pulse Monitor LB7/LLY Only
http://www.quadzillapower.com/products/index.cfm/p/Adrenaline-Chevy-01-04
+150 HP / +350 LB-FT MAX

Intake

Intake Modification or Aftermarket Intakes
Mods

PPE Intake Mod
http://www.pacificp.com/pdf/2006-2007 Airbox Modification LLY-LBZ.pdf

Aftermarket Intakes (In order of popularity)

aFe Power (Offers both Oiled and Dry filters)
http://afepower.com/shop/application_searchnew.php?diesel=true&searchtype=m ake&make=gmc

S&B (Offers both Oiled and Dry filters)
http://www.sbfilters.com/Cold-Air-Intake-Kits/Duramax

Banks Ram-Air (Optional Super-Scoop to draw from under the bumper)
http://www.bankspower.com/app/index/1

Volant (Optional under-bumper scoop)
http://volant.com/diesel_intake.asp?modelType=Duramax

K&N
http://store.knfilters.com/kits.htm

AEM Brute Force
http://www.aemonly.com/search/results.html?keywords=duramax&submitted=true

Airaid
http://www.airaid.com/Default.aspx

Injen (Available through Amsoil)
http://www.injen.com/docs/typeofvehicle/diesel.asp

Aftermarket Intake Manifold/Turbo Inlet (Mouthpiece)
aFe Power
http://afepower.com/shop/details_ne...&diesel=true&searchtype=make&make=gmc&&brandI D=25

Kodiak MP GM PART # 98011736
LBZ MP GM PART # 98011738
(Search for Part # here) http://www.gmpartsdirect.com/

Aftermarket Intercooler Tube
aFe Power
http://afepower.com/shop/application_searchnew.php?diesel=true&searchtype=m ake&make=gmc

Banks
http://www.bankspower.com/app/index/1

Intercooler

Aftermarket Intercooler

Banks
http://www.bankspower.com/app/index/1

PPE
http://www.pacificp.com/store/index.php?main_page=product_info&cPath=2_41&produc ts_id=143

Turbonetics
http://www.turboneticsinc.com/content/intercooler-kits

BD
http://www.dieselperformance.com/index.php/product/index/179P


Exhaust

MBRP (Single & Dual side-exit, Cat/Turbo-back, and Stacks)
http://www.mbrp.com/?section=Automotive

Magnaflow (Single & Dual side-exit Cat/Turbo-back)
http://www.magnaflow.com/02product/02catback.asp

Banks (Single & Dual side-exit Cat/Turbo-back)
http://www.bankspower.com/app/index/1

Silverline/Ansa (Single & Dual side-exit, Cat/Turbo-back, and Stacks)
http://www.silverlineexhaust.com/Silverline/

aFe Power (Single side-exit Cat/Turbo-back)
http://afepower.com/shop/application_searchnew.php?diesel=true&searchtype=m ake&make=gmc

Power Flow Exhaust & Grand Rock Stacks
http://www.grpipes.com/powerflow.asp

Diamond Eye (Single & Dual side-exit, Cat/Turbo-back)
http://www.diamondeyeperformance.com/products.asp?cat=exhaust&subcat=chevy/gmc


Turbo

Aftermarket Turbo

PPE (Singles listed, but Twins in the works)
http://www.pacificp.com/store/index.php?main_page=index&cPath=2_41

MPI (Twins)
http://www.maximizedperformanceinc.com/pricing.htm

ATS
http://atsdiesel.com/ats2/products_GM/use/2024314

High Tech Turbo
http://www.htturbo.com/chevy.htm

Industrial Injection (Singles & Twins)
http://www.industrialinjection.com/id54.html

Garrett
http://www.turbobygarrett.com/turbobygarrett/products/turbo_kits.html

BD
http://www.dieselperformance.com/index.php/product/index/95P


Aftermarket Exhaust Manifolds/Headers & Up-Pipes

BD (Manifold only)
http://www.dieselperformance.com/index.php/product/index/101P

RDL
http://profabperformance.com/jm/

PPE
http://www.pacificp.com/store/index.php?main_page=product_info&cPath=2_7&product s_id=216

ATS
http://atsdiesel.com/ats2/product/2044248

Fuel

Lift Pumps/Fuel Systems

AirDog
http://www.pureflowairdog.com/products.html

FASS
http://www.fassride.com/Home/tabid/37/Default.aspx

PPE
http://www.pacificp.com/store/index.php?main_page=product_info&cPath=2_7&product s_id=141

Holley
http://www.holley.com/types/Electric Pumps - Carbureted.asp

Edelbrock
http://www.edelbrock.com/automotive_new/mc/fuel_pumps/fuel_pumps_main.shtml

Aftermarket CP3 Injection Pumps

PPE
http://www.pacificp.com/store/index.php?main_page=product_info&cPath=2_7&product s_id=105

ATS
http://atsdiesel.com/ats2/product/7014290

Industrial Injection
http://www.industrialinjection.com/id86.html


Aftermarket injectors/Nozzles

Industrial Injection
http://www.industrialinjection.com/id87.html

Dynomite Diesel Performance
http://www.dynomitediesel.com/prod_display/Injectors/22/GM-Chevy+Duramax/0.php

ATS
http://atsdiesel.com/ats2/product/7034314

Transmission

Aftermarket Transmissions/Torque Converters/Shift Kits

Suncoast
http://www.suncoastconverters.com/gmc/gm_products.html

ATS
http://atsdiesel.com/ats2/products_GM/use/3094308
http://atsdiesel.com/ats2/product/3024248

PPE
http://www.pacificp.com/store/index.php?main_page=index&cPath=2_15

Precision Industries (PI-ML) Page is not accurate
http://www.converter.com/index.htm

Trans-Parts
http://www.allisontransparts.com/index.php?option=com_virtuemart&page=shop.browse&c ategory_id=9&Itemid=55

TransGo/SK
http://www.transgo.com/sk_generalmtrs.php

Bulk Parts (Trans-Go and other parts)
http://www.bulkpart.com/Merchant2/merchant.mvc?Screen=CTGY&Store_Code=2&Category_Cod e=Allison-1000

Clutch (For those lucky enough to have a ZF6)
South Bend Clutch
http://www.southbendclutch.com/chevy_catalog.html


Steering/Traction

Steering Components

PPE
http://www.pacificp.com/store/index.php?main_page=index&cPath=2_16

Super Diesel
http://www.superdieselperformance.com/

Cognito Motorsports
http://cognitomotorsports.com/store/page144.html

FabTech
http://www.fabtechmotorsports.com/applications/gm/4wd01-06-gmk2500hd.html

Crank It Up
http://www.crankitupdiesel.com/store.htm

ReadyLift
http://www.readylift.com/c-131-tie-...sic-6-lug-2500hd-2000-2010-8-lug-2wd-4wd.aspx

Traction Aids

Cal-Tracs
http://calvertracing.com/cart/ymm.php?year=2006&make=CHEVROLET&model=SILVERADO+2 500+HD


Engine

Head/Main Studs

ARP
http://www.arpdiesel.com/

Connecting Rods/Cranks

Crower
http://www.crower.com/misc/whatsnew.shtml

Carillo
http://www.carrilloind.com/Products/tabid/60/Default.aspx


Swap/Conversion

PPE Duramax Wiring Harness
http://www.pacificp.com/store/index....922f5abdec4b94

Destroked Allison 5-Speed Stand-Alone Kit
http://www.destroked.com/parts/electronics.shtml

Duramax Long Blocks
http://www.gmpartsdirect.com/
LBZ-$6873 (2007>Chevrolet/GEO>Silverado 2500 Classic)
LMM-$6832 (2008>Chevrolet>GEO>Silverado 2500)



Thanks to BriteWhiteRam, Merlin5577 and New 0mega! As well as hccumminsmoke and squeeky for helping with pics. I'm posting this without pics right now because this post is huge!

I hope others will also assist here.[/size][/font]

See less See more
#2 ·
Chevrolet LMM pics.

2008 Crew-Cab/Short-Bed LMM Duramax


Attachments

#5 ·
2003 Silverado 2500HD RC/LB 4X4.






#6 ·
2006 Chevrolet Silverado 2500HD LBZ 4x4 crew-cab short box






#7 ·
2007.5 GMC Sierra Extended Cab Long Box Z71




#8 ·
2002-CC/SB, Duramax/Allison, 4x4


Land vehicle Vehicle Car Motor vehicle Tire


Land vehicle Vehicle Car Motor vehicle Chevrolet


Land vehicle Vehicle Car Steering wheel Van

#9 ·
2002-CC/SB, Duramax/Allison, 4x4

Land vehicle Vehicle Car Tire Motor vehicle


Vehicle audio Vehicle Electronics Car Center console


Land vehicle Vehicle Car Pickup truck Chevrolet

#13 · (Edited)
LLY Information Update

Thanks to DrHolliday(Chris) for doing some research on this as well.

LLY:
Years offered: 2004.5-2005 / 2006 LLY is basically a de-tuned LBZ

Compression: 17.5:1 / 16.8:1 (2006)
Injection: Bosch High Pressure Common-rail
Power / Torque: 04.5-06; 310 HP @3000rpm / 605 LB-FT @1600 rpm.

Engine Changes from previous model:
Garrett Variable Geometry Turbocharger (VGT)
EGR Valve added
PCV now routed back through Turbo Air Intake (mouthpiece)
Redesigned Valve Covers, eliminating removal to R&R injectors and prevent fuel from pouring into crank-case
Grid Heater removed
High Idle Feature added
Early 2006 LLY model has LBZ updates including Bosch ECM and internals.

Changes to Vehicle from previous model: Higher Hood-line signifying Model Year 2005+

Thank you Chris!

#15 ·
Thanks for the help Russ... but I cant help but notice pictures of your black beauty are nowhere to be found..... :shrugs

  • Like
Reactions: Rcannon
#18 ·
I guess stock is not required as per the PM?!?!

Only difference now is the addition of dual 6" miter cut black stacks with chrome Pete clamps, even with the top of the cab and MBRP diamond plate cover. 5" from turbo back, with custom center split "even flow" Y pipe on 14" bend up pipe for flow.

Also painted the secondary CP3 (metal part) 1000*F gloss black, along with primer pump delete head. All 8 intake ports on the custom PPE race intake are filled now with nitrous inlets, W/M inlets, Hobbs and other ancillaries, loom plugs are in-line again with the delete of Edge box for DSP5 mounted in top console below the lighted E-Locker toggle and next to the PPE rail and 2K* pyro.

All boots are 200psi, triple boost gauges on the A-pillar, the rest is the same from before, barring the ATS Extreme freshin up with 5 Star converter, all T Case upgrades from Fleece and Merchant, yada yada. The rest, I think, is in the sig :D (I'll throw some more pics in below)


Attachments

#20 ·
Any chance of getting a pic of the truck?

#21 ·
Woops. Forgot the truck :bash

Last one is the track controller. Auto N2O bottle opener, auto heater, main power, nitrous1, propane, nitrous2, W/M. Clips into console and fits hand like a glove :D

I'll get some new pics when the truck dries off from the snow (and snow and more snow and snow and snow and.... :swear


Attachments

#28 ·
:whs :thumbsup

#23 ·
Beautiful truck Tony!

#29 ·
agreed, that thing is pretty sick man:thumbsup

#30 ·
Bump for pics. We have a new LLY member.

#36 ·
Well I figured it was time to move into this thread :roflol:.


Attachments

#37 ·
More of the 01.


Attachments

#38 · (Edited)
03 GMC 3500. Both trucks are ZF6 trucks too. The red crew cab is my dads 02.


Attachments

This is an older thread, you may not receive a response, and could be reviving an old thread. Please consider creating a new thread.
Top
